IKA ETS-D6

Name: IKA ETS-D6
Brand: IKA
SKU: IKA0003378100
Price: 6818.75 DKK
Availability: InStock

ITEM NUMBER IKA0003378100

Electronic contact thermometer with three patented IKA operating modes.

Description

ETS-D6

Electronic contact thermometer with three patented IKA operating modes.

with optimised PID control
RESET function
with integrated pH measuring instrument
incl. sensor H 62
Large, graphic LCD display with multilingual user guide
Without pH electrode

Ensures perfect temperature control in liquid mediums without overshooting the set temperature, even in the case of quick heating. Automatic switch-off of the temperature control function of the connected magnetic stirrer after three minutes if the temperature probe is not immersed in the medium (Error 5).

Technical Data

Temperature measuring range min. (width H62 sensor)	-10 °C
Temperature measuring range max. (width H62 sensor)	400 °C
Temperature measurement resolution	0.01 K
Accuracy of temperature measurement	±0.05 + tolerance PT1000 (DIN IEC 751 Class A) K
Set temperature resolution	±0.1 K
Heat control accuracy of medium with sensor	±0.2 K
pH measurement	yes / BNC socket female
pH measuring range	0 - 14 pH
Accuracy of pH measurement	±0.1 pH
pH measurement resolution	0.01 pH
Immersion depth max.	200 mm
Permissible ON time	100 %
Dimensions (W x H x D)	96 x 98 x 45 mm
Weight	0.2 kg
Permissible relative humidity	80 %
Protection class according to DIN EN 60529	IP 54
DC Voltage	8 - 16 V=
Current consumption	30 mA
