IKA T 25 easy clean control ULTRA-TURRAX®

ITEM NUMBER IKA0025002500

The T 25 easy clean control is a high-performance dispersing instrument with electronic speed control from 3,000 - 25,000 rpm for working volumes of 1 - 2,000 ml (H2O). The new tool S 25 EC-T-C-18G-ST allows temperature measurement and operation time detection through RFID. Device overheating is prevented by continuous temperature monitoring and the setting of temperature limits. The detection of operation time serves to guarantee regular maintenance.

Description

T 25 easy clean control ULTRA-TURRAX®

The images do not correspond to scope of delivery.

The T 25 easy clean control is a high-performance dispersing instrument with electronic speed control from 3,000 - 25,000 rpm for working volumes of 1 - 2,000 ml (H2O). The new tool S 25 EC-T-C-18G-ST allows temperature measurement and operation time detection through RFID. Device overheating is prevented by continuous temperature monitoring and the setting of temperature limits. The detection of operation time serves to guarantee regular maintenance.

All S 25 tools are compatible with T 25 easy clean control.

Key features in overview

  • Continuous temperature measurement with S 25 EC-T-C-18G-ST tool including an integrated temperature sensor
  • Operation time detection through RFID
  • Quick and easy cleaning of the easy clean dispersing tools, no disassembling required
  • Brushless motor guarantees dust-free and silent operation
  • USB interface for control and documentation via labworldsoft®
  • Timer/counter function
  • Increased safety through tool recognition and IP-class
  • Remote control with WiCo (not incl. with delivery)

The dispersing tool is not included in the scope of delivery.

Scope of delivery

  • T 25 easy clean control ULTRA-TURRAX®
  • USB Cable - USB A to Micro-B, 2 m

Technical Data

Motor rating input500 W
Motor rating output400 W
Volume range (H2O)0.001 - 2 l
Viscosity max.5000 mPas
Speed range3000 - 25000 rpm
Speed deviation2 %
Speed displayLED
Speed adjustmentstepless
Noise without element70 dB(A)
Motor principleBrushless DC
Extension arm diameter13 mm
Extension arm length160 mm
Process typebatch
Temperature displayyes
Temperature measuring range0 - 125 °C
Temperature measurement resolution0.1 K
Accuracy of temperature measurement±1 K
Timeryes
Timer displayLED
Permissible ON time100 %
Dimensions (W x H x D)89 x 270 x 161 mm
Weight3 kg
Permissible ambient temperature5 - 40 °C
Permissible relative humidity80 %
Protection class according to DIN EN 60529IP 30
USB interfaceyes
Voltage220 - 240 V
Frequency50/60 Hz
Power input500 W
Specifications
ITEM NUMBER IKA0025002500
Quantity / pk 1
Unit pcs
Minimum order 1
Supplier's item number 0025002500
CE-godkendt Ja
