Binder FED115-230V Varmeskab, FK, 116 l

ITEM NUMBER BIN90100293

Benefits

  • Best energy efficiency on the market.
  • Excellent temporal and spatial temperature accuracy.
  • USB connection for recording data.
  • Temperature range up to 300 °C.
Description

BINDER heating chambers of the FED Avantgarde.Line series provide almost unlimited capacity and are particularly adaptable. With advanced timing functions and a controllable fan, temperature and convection conditions are easily controlled.

Benefits

  • Best energy efficiency on the market
  • Excellent temporal and spatial temperature accuracy
  • USB connection for recording data
  • Temperature range up to 300 °C

Important characteristics

  • Temperature range: ambient temperature plus 10 °C to 300 °C
  • Up to 30% lower energy consumption compared to conventional units on the market
  • High temperature accuracy thanks to APT.line technology
  • Adjustable fan speed
  • Controller with LCD display and enhanced time functions
  • Electromechanical control of the exhaust air flap
  • 2 chrome-plated racks
  • Units up to 115 liters are stackable
  • Class 2 integrated independent adjustable temperature safety device (DIN 12880) with visual alarm
  • Ergonomic handle design
  • Ethernet interface
  • USB port for recording data

Performance Data Temperature

DesignationFED115-230VFED115UL-120V
Temperature range+10 °C above ambient temperature to 300 °C+10 °C above ambient temperature to 300 °C
Temperature uniformity at 150°C1.2 ± K1.2 ± K
Temperature fluctuation at 150°C0.3 ± K0.3 ± K
Heating up time to 150°C18 min18 min
Recovery time after door was opened for 30 s at 150°C4 min4 min

Air change data

DesignationFED115-230VFED115UL-120V
Air change rate at 100°C32 x/h32 x/h

Electrical data

DesignationFED115-230VFED115UL-120V
Rated Voltage230 V120 V
Power frequency50/60 Hz60 Hz
Nominal power1,3 kW1,4 kW
Unit fuse6,3 A12,5 A
Phase (Nominal voltage)1~1~

Measures

DesignationFED115-230VFED115UL-120V
Interior volume116 L116 L
Net weight of the unit (empty)54 kg54 kg
Load per rack30 kg30 kg
Permitted load150 kg150 kg
Wall clearance back160 mm160 mm
Wall clearance sidewise100 mm100 mm

Housing dimensions not incl. fittings and connections

DesignationFED115-230VFED115UL-120V
Width net710 mm710 mm
Height net705 mm705 mm
Depth net605 mm605 mm

Internal Dimensions

DesignationFED115-230VFED115UL-120V
Interior width550 mm550 mm
Interior height550 mm550 mm
Interior depth385 mm385 mm
Unit doors11

Environment-specific data

DesignationFED115-230VFED115UL-120V
Sound-pressure level43 dB(A)43 dB(A)
Energy consumption at 100°C215 Wh/h215 Wh/h
Energy consumption at 150°C340 Wh/h340 Wh/h

Fixtures

DesignationFED115-230VFED115UL-120V
Number of shelves (std./max.)2/52/5
Specifications
ITEM NUMBER BIN90100293
Quantity / pk 1
Unit pcs
Minimum order 1
Supplier's item number 9010-0293
CE-godkendt Ja
