Binder BD400 Inkubator, std., CL, 100°C, 400 liter

ITEM NUMBER BIN90100073

Benefits

  • Safe and reproducible results even under high batch throughputs in long-term operation
  • Disinfection routine at 100 °C
  • Stable atmosphere by inner glass door
Description

The BINDER incubator of the BD series with natural convection is the specialist in long-term and stable continuous operation. This incubator is specially designed for gentle incubation of organisms, as well as conditioning of heat-sensitive media or microbiological heating.

Benefits

  • Safe and reproducible incubation even under high batch throughputs in long-term operation
  • Disinfection routine at 100 °C
  • Stable atmosphere by inner glass door

Important characteristics

  • Temperature range: room temperature plus 5 °C to 100 °C
  • APT.line preheating chamber technology
  • natural convection
  • Adjustable exhaust air flap
  • Controller with timer functions
  • Inner door made of tempered safety glass
  • 2 chrome-plated racks
  • Units up to 115 liters are stackable
  • Class 3.1 independent temperature safety device (DIN 12880) with visual temperature alarm
  • Computer interface: RS 422

Incubator with natural convection from BINDER

If you are looking for stable incubation processes guaranteed, you need look no further than incubators from BINDER. Series BD incubators function with natural convection and, thanks to their state-of-the-art technical equipment, are a reliable choice for the incubation of microbiological cultures.
This BINDER incubator with natural convection comes in a range of versions and sizes. Operating within a temperature range of between 5 °C and 100 °C, they are equipped with the proven APT.line preheating chamber technology and an adjustable exhaust air flap. The inner door is made from tempered safety glass, guaranteeing a stable atmosphere.

Incubator with natural convection for optimum, reproducible results

This BINDER incubator with natural convection is really easy to use thanks to the controller with timer functions and the visual temperature alarm. The units can be stacked on top of one another for an optimum ratio between stand space and usable space.
Plus, compared to similar incubators, the units from BINDER boast high levels of temperature accuracy, excellent usability, and options for ease of cleaning. The incubator with natural convection guarantees results that are reproducible at any time, with uniform incubation conditions even under high batch throughputs in long-term operation. These incubators are ideal for all incubation processes within the fields of research, production, and quality assurance.

Performance Data Temperature

DesignationBD400-230VBD400UL-120V
Temperature range+5 °C above ambient temperature to 100 °C+5 °C above ambient temperature to 100 °C
Temperature uniformity at 37°C0.5 ± K0.5 ± K
Temperature fluctuation at 37°C0.1 ± K0.1 ± K
Heating up time to 37°C120 min120 min
Recovery time after door was opened for 30 s at 37°C10 min10 min

Electrical data

DesignationBD400-230VBD400UL-120V
Rated Voltage230 V120 V
Power frequency50/60 Hz60 Hz
Nominal power0,85 kW0,85 kW
Unit fuse12,5 A12,5 A
Phase (Nominal voltage)1~1~

Measures

DesignationBD400-230VBD400UL-120V
Interior volume400 L400 L
Net weight of the unit (empty)135 kg135 kg
Load per rack35 kg35 kg
Permitted load90 kg90 kg
Wall clearance back160 mm160 mm
Wall clearance sidewise100 mm100 mm

Housing dimensions not incl. fittings and connections

DesignationBD400-230VBD400UL-120V
Width net1,235 mm1,235 mm
Height net1,025 mm1,025 mm
Depth net765 mm765 mm

Internal Dimensions

DesignationBD400-230VBD400UL-120V
Interior width1,000 mm1,000 mm
Interior height800 mm800 mm
Interior depth500 mm500 mm
Unit doors22

Environment-specific data

DesignationBD400-230VBD400UL-120V
Energy consumption at 37°C56 Wh/h56 Wh/h

Fixtures

DesignationBD400-230VBD400UL-120V
Number of shelves (std./max.)2/92/9
Specifications
ITEM NUMBER BIN90100073
Quantity / pk 1
Unit pcs
Minimum order 1
Supplier's item number 9010-0073
Type Udstyr
CE-godkendt Ja
