IKA MATRIX Delta Plus shaker

ITEM NUMBER IKA0030000717
Description

Matrix Delta plus heats and cools reliably with variable inserts. Whether blood samples, pharmaceutical agents, DNA/RNA samples or ELISA assays - reaction vials and plates with even the smallest volumes are reliably tempered in all laboratory applications.
In addition, Matrix Delta plus comes with numerous user-friendly features:

  • Large and clear display with a convenient menu structure allows for an intuitive operation
  • Reduced waiting time through fast heating and cooling rates of up tp 5.5 °C/min (heating) or 2 °C/min (cooling, at set-point temperature between ambient temperature and 30 °C below ambient temperature)
  • Firm quick-release fastener for quick and easy changing of the inserts/attachments as well as an automatic attachment detection
  • Automatic performance of heating and cooling tasks through programmable ramps
  • Aluminum die cast housing ensures secure positioning, excellent stability and everyday robustness
    The device is ideally suited for numerous applications in laboratories, such as:
  • Tempering of samples
  • Synthesis of cDNA
  • Enzyme-catalysed linking of RNA or DNA (ligation)
  • Gentle thawing of sample material
  • Structural change of DNA, RNA and proteins (denaturation)
  • ELISA assays

Maximun load [kg]: 0.3
Permissible ON time [%]: 100
Timer: yes
Timer display: TFT
Time setting min. : 1
Time setting max. [min]: 6000
Operating mode: timer, continuous and program operation
Touch function: no
Working with microtiter plates: yes
Working temperature min. [°C]: room temp. -30
Temperature setting range min. [°C]: -10
Heating temperature max. [°C]: 110
Heat output [W]: 100
Heat control: TFT
Set temperature resolution [±°C]: 1
Temperature control accuracy [±°C]: 0.5
Temperature stability [°C]: 0.5
Temperature homogenity [±°C]: 0.5
Heating rate [°C/min]: 5.5
Temperature display: yes
Cooling Rate [°C/min]: 2
Cooling Power [W]: 72
embedded cooling unit: yes
Number of exchangable attachments: 10
Fixed safety circuit [°C]: 145
Dimensions (W x H x D) [mm]: 216 x 127 x 351
Weight [kg]: 9.5
Permissible ambient temperature [°C]: 5 - 40
Permissible relative humidity [%]: 80
Protection class according to DIN EN 60529: IP 21
RS 232 interface: yes
USB interface: yes
Bluetooth interface: no
Analog output: no
Voltage [V]: 100 - 240
Frequency [Hz]: 50/60
Power input [W]: 230
Fuse: 2x T4A 250V

Specifications
ITEM NUMBER IKA0030000717
Quantity / pk 1
Unit pcs
Minimum order 1
Supplier's item number 0030000717
Type Orbital | Varme
CE-godkendt Ja
