Binder VDL56 Vakuumtørreskab, FS, 55 liter

ITEM NUMBER BIN96300010

Benefits

  • Fast, gentle drying.
  • Optimum heat transfer through large thermal conducting plates.
  • Safe work thanks to proven safety concept.
  • Also option of modular complete system with vacuum pump and pump chamber.
Description

BINDER VDL series safety vacuum drying chambers ensure maximum safety when drying organic solvents. Explosion-protected unit with classification according to ATEX directive 2014/34/EU: EX II 2/3/- G IIB T3 Gb/Gc/- X.

Benefits

  • Fast, gentle drying
  • Optimum heat transfer through large thermal conducting plates
  • Safe working thanks to ATEX-compliant safety concept
  • Also option of modular complete system with vacuum pump and pump chamber

Important characteristics

  • Temperature range: Ambient temperature +9 °C to +110 °C
  • ATEX conformity for units: EX II 2/3/- G IIB T3 Gb/Gc/- X
  • Intuitive touchscreen controller with graphical pressure and temperature display
  • Program-controlled drying monitoring with automatic ventilation at end of process
  • Internal data logger, measured values can be read out in open format via USB
  • Pressure control device for heating activated from < 100 mbar
  • 2 aluminum expansion racks, can be custom-positioned
  • Universal connection for ventilation with ambient air or inert gas
  • DN 16 universal access port with small flange and blind flange, for positioning sensors or supply lines in the chamber
  • Shatterproof, spring-mounted safety glass panel
  • Large viewing window
  • Computer interface: Ethernet

Optional equipment

  • Expansion racks - Choice of aluminum or stainless steel racks depending on the application requirements
  • Analogue output for temperature and pressure signals - for external monitoring and evaluation of the process parameters, integration into in-house systems is possible
  • Universal ventilation - Selection of different ventilation by air or inert gas
  • Universal access port DN 40 - for the introduction of external measuring devices
  • Multi Management Software APT-COM - Manage, record and document device parameters
  • Services - extensive services ensure correct device function

Performance Data Temperature

DesignationVDL056-230VVDL056-120V
Temperature range+9 °C above ambient temperature to 110 °C+9 °C above ambient temperature to 110 °C
Temperature uniformity at 100°C1.2 ± K1.2 ± K
Temperature fluctuation at 100°C0.1 ± K0.1 ± K
Heating up time to 100°C140 min140 min

Vacuum Data

DesignationVDL056-230VVDL056-120V
Leckrate0,01 bar/h0,01 bar/h

Electrical data

DesignationVDL056-230VVDL056-120V
Rated Voltage200...230 V100...120 V
Power frequency50/60 Hz50/60 Hz
Nominal power1,4 kW1,4 kW
Unit fuse8,0 A16,0 A
Phase (Nominal voltage)1~1~

Connections

DesignationVDL056-230VVDL056-120V
Vacuum connection with small flange16 DN mm16 DN mm
Measuring access port with small flange16 DN mm16 DN mm

Measures

DesignationVDL056-230VVDL056-120V
Interior volume55 L55 L
Net weight of the unit (empty)104 kg104 kg
Load per rack20 kg20 kg
Permitted load60 kg60 kg
Wall clearance back100 mm100 mm
Wall clearance sidewise70 mm70 mm

Housing dimensions not incl. fittings and connections

DesignationVDL056-230VVDL056-120V
Width net
Height net
Depth net

Internal Dimensions

DesignationVDL056-230VVDL056-120V
Interior width400 mm400 mm
Interior height400 mm400 mm
Interior depth343 mm343 mm
Viewing window width420 mm420 mm
Viewing window height420 mm420 mm
Unit doors11

Environment-specific data

DesignationVDL056-230VVDL056-120V
Sound-pressure level40 dB(A)40 dB(A)
Energy consumption at 100°C180 Wh/h180 Wh/h

Fixtures

DesignationVDL056-230VVDL056-120V
Number of shelves (std./max.)2/52/5
Specifications
ITEM NUMBER BIN96300010
Quantity / pk 1
Unit pcs
Minimum order 1
Supplier's item number 9630-0010
CE-godkendt Ja
