Pneumatic HPLC Pump S1950 w/ 100ml/min head, SS

Varenr. KNA50751

Pneumatic HPLC Pump Smartline S1950 with 100 ml/min pump head, stainless steel

Beskrivelse

A50751
Smartline Pneumatic Pump 1950 with 100 ml pump head. The Smartline Pneumatic Pump 1950, powered by compressed air, has been designed for solvent delivery in process chemistry, column packing or preparative chromatography.

Application areas:

  • Packing of HPLC columns at pressures up to 1000 bar
  • Delivery of supercritical fluids such as CO2 (with mounted pump head cooling device)
  • Metering against constant pressure

The delivery flow rate depends on the compressed air supply and the back pressure of the column or system. Maximum delivery flow rate can be reached at minimum liquid pressure (below 1 bar). The minimum liquid flow rate (approx. 5 ml/min) is achieved at highest back pressure.

The Smartline Pneumatic Pump 1950 (A50751) has a 100 ml stainless steel pump head and can be operated at maximal 1000 bar back pressure for solvent delivery.

Key features

  • No electrical connection required, therefore suitable for operation in hazardous environments
  • Can be configured with four different pump heads (double piston design)
  • Easily changeable pump heads
  • Pump heads can be equipped with eluent cooling or heating device
  • Maintenance-free pump drive
  • Using the 100 ml pump head, the external air pressure should not exceed 4.2 bar in order not to damage the pump head or pump mechanics.
Specifikationer
Varenr. KNA50751
Antal / pk 1
Enhed stk
Min. bestilling 1
Leverandørens varenummer A50751
UNSPSC 41105106
Type Trykluft
Type 2 Udstyr
Flow 300 ml/min
Vægt 10,2
Tryk max (bar) 1000
Dimensioner 220 x 185 x 340 mm
